PSB-S9 Thermistor
A micro-miniature thermistor with a super-fast response
- The most compact glass-encapsulated thermistor
- Chip with gold electrodes
- High-level heat resistance and environmental stability secured by glass encapsulation
- Long-term stability in resistance
- High-volume supply in high quality by integrated automatic production
Features
| Applications |
Suitable for medical and other equipment requiring a super-fast response, and also for test equipment for designing thermal components
|
|---|---|
| Operating temperature | -50 to +250℃ |
| Thermal time constant | Approx. 0.6 sec. |
| Dissipation constant | Approx. 0.15mW/℃ |
| Insulation resistance | Min. 10MΩ at 50VDC |
Note) Unless otherwise stated, all thermal time constants and dissipation constants are measured in still air.
V-I characteristics
